- Peak Power 1300W
- PP X-motif Cone with Diamond Array Pattern
- Closed Yoke with Advanced Airflow Control
- Stress Controlled Spider
- Robust Thermal Management System
X-Motif Cone with Diamond Array Pattern
X-Motif Cone controls resonance frequency and cuts unnecessary frequency, delivering powerful and solid bass response.
Closed Yoke with Advanced Airflow Control
The KFC-W2541 has a robust thermal management system implemented with an Aluminum Bobbin, Closed Yoke Design, and Advanced Airflow Control.
Stress Controlled Spider
Computer-optimized damper controls stress and increases mechanical durability.
The Best Match
KFC-W2541 subwoofer is precisely power matched with the KAC-D5101 amplifier.
Optional CA-101G Subwoofer Grille Ready
Specs
ELECTRICAL
Impedance (Ω) 4
Peak Input Power (W) 1300
RMS Power (W) 300
Sensitivity (dB at 1m) 84
Frequency Response (Hz) 33 ~ 300
MOUNTED SPEAKER
Size 250mm 10 inch
Diaphragm Paper
Cap Injection PP
Surround Urethane
Basket Steel
Gasket ABS
Magnet Ferrite φ134-φ70-t30
DIMENSION
Width 275mm 10 - 13/16 inch
Height 275mm 10 - 13/16 inch
Cut-out Diameter 230mm 9 - 1/16 inch
Depth 142.2mm 5 - 5/8 inch
Mounting Depth 124mm 4 - 7/8 inch
WEIGHT
Woofer without Gasket 4.0 kg 8.8 lb
Gross Weight 4.6 kg 10.1 lb
Weight of Magnet 1560 g 54.9 oz
ACCESSORY Instruction Manual, Warranty Card
SPECIAL FEATURE Injection PP X-motif Cone with
Diamond Array Pattern
Closed Yoke with Advanced
Airflow Control
Aluminum Bobbin
