- Peak Power 1300W
- PP X-motif Cone with Diamond Array Pattern
- Closed Yoke with Advanced Airflow Control
- Stress Controlled Spider
- Robust Thermal Management System
X-Motif Cone with Diamond Array Pattern
X-Motif Cone controls resonance frequency and cuts unnecessary frequency, delivering powerful and solid bass response.
Closed Yoke with Advanced Airflow Control
The KFC-W3041 has a robust thermal management system implemented. with an Aluminum Bobbin, Closed Yoke Design, and Advanced Airflow Control.
Stress Controlled Spider
Computer-optimized damper controls stress and increases mechanical durability.
The Best Match
KFC-W3041 subwoofer is precisely power matched with the KAC-D5101 amplifier.
Optional CA-121G Subwoofer Grille Ready
Specs
ELECTRICAL
Impedance (Ω) 4
Peak Input Power (W) 2000
RMS Power (W) 300
Sensitivity (dB at 1m) 85
Frequency Response (Hz) 29 ~ 300
MOUNTED SPEAKER
Size 300mm 12 inch
Diaphragm Paper
Cap Injection PP
Surround Urethane
Basket Steel
Gasket ABS
Magnet Ferrite φ134-φ70-t30
DIMENSION
Width 326mm 12 - 13/16 inch
Height 326mm 12 - 13/16 inch
Cut-out Diameter 279mm 11 inch
Depth 155.4mm 6 - 1/8 inch
Mounting Depth 137mm 5 - 3/8 inch
WEIGHT
Woofer without Gasket 4.2 kg 9.3 lb
Gross Weight 5.0 kg 11.0 lb
Weight of Magnet 1560 g 54.9 oz
ACCESSORY Instruction Manual, Warranty Card
SPECIAL FEATURE Injection PP X-motif Cone with
Diamond Array Pattern
Closed Yoke with Advanced
Airflow Control
Aluminum Bobbin
